GIRO AR 1 GRAVEL BIKE
SPECIFICATIONS
COMPARE
SHARE PRINT FIND A STOCKIST SEND EMAIL

This form will not subscribe you to any information you haven’t already requested from us.


This form will not subscribe you or your friend to any information you haven't already requested from us.



SHARE PRINT FIND A STOCKIST SEND TO EMAIL
Category Road
Family Sport Road
Model Giro AR 1
Sizes SM, SM/MD, MD, LG
Colour Grey / White
Frame ADT 6061 Formtech Alloy with Rack mounts, Flat mount Disc Brake
Fork Carbon Fibre 1-1/8" Alloy Steerer
Front Derailleur Shimano Claris 2000
Rear Derailleur Shimano Claris 2000
Shifters Shimano Claris 2000 16-Speed
Crankset Shimano Claris 2000 Compact 50/34T
Brakes Tektro Lyra Mechanical Disc, 160mm Rotors
Brake Levers Shimano Claris
Wheelset / Rims Alex MD17 Double-wall Alloy 32H
Hubs Alloy Disc QR Front, Cassette Rear
Spokes Stainless Steel
Cassette Shimano HG50 11-34T 8-Speed
Handlebar Zero Attack Pro-S 31.8mm
Handlebar Stem Zero Attack Pro 31.8mm
Headset Integrated Sealed Bearing Aheadset 1-1/8"
Grips Zero Gel Wrap
Tyres Schwalbe Lugano K-Guard 700 x 28c
Saddle Zero Sport
Seat Post Zero Attack 27.2mm
Bottom Bracket Shimano Claris
Chain KMC Z7

Geometry

  SM SM/MD MD LG
1 Seat Tube Length (C-Top) 460 510 540 560
2 Horizontal Top Tube Length 520 540 560 580
3 Head Tube Length 130 150 170 190
4 Head Angle 71.5 72 72 72
5 Seat Angle 75.5 73.5 73 73
6 Chainstay Length 435 435 435 435
7 BB Drop 60 60 60 60
8 Wheelbase 1019 1015 1030 1050
The following are not displayed.
  Stack to Head Tube centre 530 551 570 590
  Reach to Head Tube centre 383 377 386 400
  Top Tube Length 507 525 545 565
  Standover Height 733 766 790 808
  Front Centre 591 587 602 622
  Fork Offset 45 45 45 45
  Trail 66 63 63 63
  Handlebar Width 400 420 420 440
  Stem Length 90 90 100 110
  Crank Length 170 170 175 175
  Seat Tube Length (C-C) 415 465 495 515
