Add bikes to your compare list to view them alongside each other using the COMPARE tab
| Category | Road |
|
|
| Family | Performance |
|
|
|
| Model | Corsa SL 1 Disc |
|
|
|
| Sizes | S, S/M, M, M/L, L |
|
|
|
| Colour | Blue / Orange |
|
|
|
| Frame | ADT R5 Carbon, Performance Road Geometry, Universal component capability, 142x12mm Thru axle, Flat Mount Disc Brake |
|
|
|
| Fork | ADT R5 Carbon Integrated with 1.5"-1 1/8" Steerer, 100x12mm Thru Axle, Flat Mount Disc Brake |
|
|
|
| Front Derailleur | Shimano 105 5800 |
|
|
|
| Rear Derailleur | Shimano 105 5800 |
|
|
|
| Shifters | Shimano ST-RS505 22-Speed with Shimano Gear cables |
|
|
|
| Crankset | Shimano 105 5800 Compact 52/36T |
|
|
|
| Brakes | Shimano BR-RS505 Hydraulic Disc, 140mm Rotors |
|
|
|
| Brake Levers | Shimano RS505 Hydraulic Disc |
|
|
|
| Wheelset / Rims | Shimano RS170 Disc Wheelset |
|
|
|
| Cassette | Shimano 105 5800 11-28T 11-Speed |
|
|
|
| Handlebar | Zero Attack Pro-S 31.8mm |
|
|
|
| Handlebar Stem | Zero Attack Pro 31.8mm |
|
|
|
| Headset | Tapered Integrated Aheadset 1-1/8"- 1.5" |
|
|
|
| Grips | Zero Suede Micro Wrap |
|
|
|
| Tyres | Schwalbe Durano RaceGuard 700 x 25c with Superlite Tubes |
|
|
|
| Saddle | Zero Sport |
|
|
|
| Seat Post | Zero Attack Team Carbon 27.2mm |
|
|
|
| Bottom Bracket | Shimano SM-BB71 Press Fit |
|
|
|
| Chain | KMC X11 |
|
|
|
Geometry
| S | S/M | M | M/L | L | ||
| 1 | Seat Tube Length (C-Top) | 455 | 470 | 485 | 505 | 525 |
|
|
||||||
| 2 | Horizontal Top Tube Length | 520 | 535 | 550 | 565 | 580 |
|
|
||||||
| 3 | Standover Height | 731 | 744 | 760 | 778 | 797 |
|
|
||||||
| 4 | Head Tube Length | 110 | 125 | 145 | 165 | 190 |
|
|
||||||
| 5 | Head Angle | 72.5 | 72.5 | 73 | 73.5 | 73.5 |
|
|
||||||
| 6 | Seat Angle | 74.5 74 | 73 | 73 | 72.5 | |
|
|
||||||
| 7 | BB Drop | 70 | 70 | 70 | 70 | 70 |
|
|
||||||
| 8 | Chainstay Length | 405 | 405 | 405 | 405 | 405 |
|
|
||||||
| 9 | Wheelbase | 964 | 975 | 975 | 985 | 994 |
| The following are not displayed. | ||||||
| Stack to Head Tube centre | 511 | 527 | 545 | 568 | 592 | |
|
|
||||||
| Reach to Head Tube centre | 379 | 384 | 383 | 391 | 393 | |
|
|
||||||
| Seat Tube Length (C-C) | 440 | 453 | 470 | 490 | 511 | |
|
|
||||||
| Top Tube Length | 509 | 523 | 535 | 548 | 562 | |
|
|
||||||
| Front Centre | 569 | 580 | 580 | 590 | 600 | |
|
|
||||||
| Fork Offset | 45 | 45 | 45 | 45 | 45 | |
|
|
||||||
| Trail | 60 | 60 | 57 | 54 | 54 | |
|
|
||||||
