| Category | Road |
|
|
| Family | Performance |
|
|
|
| Model | Corsa DR 1 Disc |
|
|
|
| Sizes | S, S/M, M, M/L, L |
|
|
|
| Colour | Grey / Black |
|
|
|
| Frame | ADT R4 Carbon, Performance Road Geometry, Universal component capability |
|
|
|
| Fork | ADT R4 Monocoque Carbon Integrated with 1 1/4"-1 1/8" Steerer |
|
|
|
| Front Derailleur | Shimano 105 5800 |
|
|
|
| Rear Derailleur | Shimano 105 5800 |
|
|
|
| Shifters | Shimano 105 5800 22-Speed with Shimano Gear cables |
|
|
|
| Crankset | Shimano RS-500 Compact 52/36T |
|
|
|
| Brakes | Shimano BR-RS505 Hydraulic Disc, 140mm Rotors |
|
|
|
| Brake Levers | Shimano RS505 Hydraulic Disc |
|
|
|
| Wheelset / Rims | Shimano RS170 Disc Wheelset |
|
|
|
| Cassette | Shimano 105 5800 11-28T 11-Speed |
|
|
|
| Handlebar | Zero Attack Pro-S 31.8mm |
|
|
|
| Handlebar Stem | Zero Attack Pro 31.8mm |
|
|
|
| Headset | Tapered Integrated Aheadset 1-1/8" - 1-1/4" |
|
|
|
| Grips | Zero Suede Micro Wrap |
|
|
|
| Tyres | Schwalbe Durano RaceGuard 700 x 25c with Superlite Tubes |
|
|
|
| Saddle | Zero Sport |
|
|
|
| Seat Post | Aero Carbon |
|
|
|
| Bottom Bracket | Shimano S-BB71 Press Fit |
|
|
|
| Chain | KMC X11 |
|
|
|
Geometry
| S | S/M | M | M/L | L | ||
| 1 | Seat Tube Length (C-Top) | 480 | 495 | 510 | 527 | 550 |
|
|
||||||
| 2 | Horizontal Top Tube Length | 520 | 535 | 550 | 565 | 580 |
|
|
||||||
| 3 | Head Tube Length | 110 | 123 | 143 | 163 | 188 |
|
|
||||||
| 4 | Head Angle | 72.5 | 72.5 | 73 | 73.5 | 73.5 |
|
|
||||||
| 5 | Seat Angle | 74.5 | 74 | 73 | 73 | 72.5 |
|
|
||||||
| 6 | Chainstay Length | 405 | 405 | 405 | 405 | 407 |
|
|
||||||
| 7 | BB Drop | 70 | 70 | 68 | 68 | 68 |
|
|
||||||
| 8 | Wheelbase | 963 | 974 | 975 | 986 | 997 |
| The following are not displayed. | ||||||
| Stack to Head Tube centre | 513 | 525 | 544 | 564 | 588 | |
|
|
||||||
| Reach to Head Tube centre | 378 | 385 | 384 | 393 | 395 | |
|
|
||||||
| Seat Tube Length (C-C) | 458 | 473 | 495 | 512 | 528 | |
|
|
||||||
| Top Tube Length | 510 | 526 | 540 | 553 | 564 | |
|
|
||||||
| Standover Height | 744 | 758 | 775 | 795 | 814 | |
|
|
||||||
| Front Centre | 569 | 579 | 580 | 590 | 600 | |
|
|
||||||
| Fork Offset | 45 | 45 | 45 | 45 | 45 | |
|
|
||||||
| Trail | 60 | 60 | 57 | 54 | 54 | |
|
|
||||||
| Handlebar Width | 400 | 420 | 420 | 420 | 440 | |
|
|
||||||
| Stem Length | 80 | 90 | 100 | 100 | 110 | |
|
|
||||||
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | |
|
|
||||||
