| Category | MTB |
|
|
| Family | Sport MTB |
|
|
|
| Model | Montari 3 |
|
|
|
| Sizes | S, M, L, XL, XXL |
|
|
|
| Colour | Charcoal |
|
|
|
| Frame | ADT Custom FormTech 6061 Alloy, Integrated Head Tube, Forged Dropouts, Internal Cable Routing |
|
|
|
| Fork | SR Suntour XCT HLO, 100mm Travel, Pre-Load Adjust, Hydraulic Lock-out. |
|
|
|
| Front Derailleur | Shimano M2000 |
|
|
|
| Rear Derailleur | Shimano Altus M370 |
|
|
|
| Shifters | Shimano Altus M2000, 27 Speed |
|
|
|
| Crankset | Shimano M2000, 40/30/22T |
|
|
|
| Brakes | Shimano M315 Hydraulic Disc, 160mm Rotors |
|
|
|
| Brake Levers | Shimano M315 |
|
|
|
| Wheelset / Rims | Weinmann XRD28 Double-wall Alloy, 32H |
|
|
|
| Hubs | Shimano TX505 Disc |
|
|
|
| Spokes | Stainless Steel |
|
|
|
| Cassette | Shimano HG200 Cassette, 9 Speed, 11-34T |
|
|
|
| Handlebar | 6061 Alloy Riser, 31.8mm |
|
|
|
| Handlebar Stem | Alloy, 4-Bolt Clamp, 31.8mm |
|
|
|
| Headset | Semi-Integrated Threadless, 1-1/8" |
|
|
|
| Grips | Zero Strike Gel Dual Compound |
|
|
|
| Pedals | Nylon Platform |
|
|
|
| Tyres | Kenda Slant 6 2.20” |
|
|
|
| Saddle | Zero Zealth Sport |
|
|
|
| Seat Post | Alloy, 27.2mm |
|
|
|
| Bottom Bracket | Cartridge |
|
|
|
| Chain | KMC Z-99 |
|
|
|
Geometry
| SM | MD | LG | L | XXL | ||
| 1 | Seat Tube Length (C-Top) | 400 | 445 | 480 | 525 | 565 |
|
|
||||||
| 2 | Horizontal Top Tube Length | 570 | 590 | 605 | 620 | 625 |
|
|
||||||
| 3 | Standover Height | 738 | 763 | 785 | 815 | 844 |
|
|
||||||
| 4 | Head Tube Length | 115 | 125 | 125 | 135 | 145 |
|
|
||||||
| 5 | Head Angle | 69.5 | 70 | 71 | 71 | 71.5 |
|
|
||||||
| 6 | Seat Angle | 73.5 | 73.5 | 73.5 | 73.5 | 73 |
|
|
||||||
| 7 | BB Drop | 52 | 52 | 70 | 70 | 70 |
|
|
||||||
| 8 | Chainstay Length | 430 | 430 | 440 | 440 | 440 |
|
|
||||||
| 9 | Wheelbase | 1069 | 1084 | 1095 | 1111 | 1104 |
| The following are not displayed. | ||||||
| Stem Length | 75 | 75 | 75 | 90 | 105 | |
|
|
||||||
| Crank Length | 170 | 175 | 175 | 175 | 175 | |
|
|
||||||
| Front Centre | 644 | 659 | 665 | 680 | 673 | |
|
|
||||||
| BB Height | 302 | 302 | 306 | 304 | 304 | |
|
|
||||||
