PISTA PRO TRACK BIKE
SPECIFICATIONS
COMPARE
SHARE PRINT FIND A STOCKIST SEND EMAIL

This form will not subscribe you to any information you haven’t already requested from us.


This form will not subscribe you or your friend to any information you haven't already requested from us.



SHARE PRINT FIND A STOCKIST SEND TO EMAIL
Category Road
Family Track
Model Pista Pro
Sizes SM, MD, LG, XL
Colour Black
Frame ADT 7005 UL Ultralite Aero Alloy, Stainless Steel Dropout Plates
Fork Carbon Fibre with 1-1/8" Cr-Mo Steerer
Crankset Truvativ Omnium Track with 48T 144pcd Chainring
Wheelset / Rims Pista Aero 28H
Hubs Alloy Sealed Bearing Track Nutted
Spokes Stainless Steel
Cassette 16T Sprocket
Handlebar Zero Attack Pro-S 31.8mm
Handlebar Stem Zero Attack Pro 31.8mm
Headset Integrated Sealed Bearing Aheadset 1-1/8"
Grips Zero Suede Micro Wrap
Tyres Kenda Kountach 700 x 23c Folding
Saddle Prologo Kappa Evo
Seat Post Zero Attack 27.2mm
Bottom Bracket Truvativ GXP
Chain KMC Z-510HX

Geometry

Geometry Fit Calculator
  SM MD LG XL
1 Seat Tube Length (C-Top) 460 485 505 525
2 Horizontal Top Tube Length 515 540 570 590
2 Horizontal Top Tube Length 515 540 570 590
3 Standover Height 735 756 773 793
4 Head Tube Length 110 130 150 175
5 Head Angle 73.5 74 74 74
6 Seat Angle 75 74.5 74 74
7 BB Drop 50 50 50 50
8 Chainstay Length 396 396 396 396
9 Front Centre 562 578 604 624
10 Wheelbase 952 969 985 1014
The following are not displayed.
  Reach to Head Tube centre 389 404 424 437
  Stack to Head Tube centre 501 522 541 565
  Seat Tube Length (C-C) 420 446 466 485
  Top Tube Length 503 528 556 576
  Fork Offset 35 35 35 35
  Trail 64.2 61.1 61.1 61.1
  Handlebar Width 400 420 420 420
  Stem Length 90 100 110 110
  Crank Length 165 165 170 170
